Metalized Sapphire Window Example

Unique manufacturing process solves metalized sapphire windows problem

Problem: A manufacturer of medical endoscopes needed metalized sapphire windows with extremely smooth optically polished faces to allow for hermetic sealing into a Nickel 200 tube that was brazed to the sapphire.

Solution: China Precision Ceramic recommended a unique manufacturing process at China Precision Ceramic which would improve the overall quality of the sapphire window while allowing for improved hermetic sealing in order to autoclave the endoscope.

Result: The manufacturing changes in the orientation of the sapphire window allowed for creating a strong hermetic seal which further enhanced the ability to autoclave the endoscope resulting in a 35% increase in overall yield on the final brazed sub-assembly.
